Fibershield®-P

The premium textile fire protection curtain for high demands and large dimensions

Product description

Ideal for efficient fire protection of large dimensions: The textile fire protection curtain Fibershield-P is approved for widths up to 10 m and drop lengths of up to 7.6 m. Larger dimensions are technically feasible. Different classifications can be achieved flexibly by using different types of fabric. The curtain can be moved with just one drive system. As standard, Fibershield-P is equipped with the tried and tested "Gravigen" drive, which closes without requiring an external power source. With numerous design variants, Fibershield-P offers plenty of scope for customer-specific solutions.

Fibershield-P

Type

Textile fire protection curtain

Achievable protection goals

EI - with fire load free zone • EI - with sprinklers

Proof of usability

General technical approval (Z-6.60-2127)

Fabric

Heliotex • Protex 1100.1 A2

Fire load free zone

Heliotex: EI 30/60/90min 20/30/50 cm • Protex: EI 30/60/90min 100/150/200 cm

Verification

Z-6.60-2127 • UB III/B-07-010-1 • LP-1216.2/02 • UB III/08-033 • UB III/B-04-045 • UB 3.1/ 09-018 • UB 3.3/09-202 • UU IV/00-39-1 • 08/32309876 • 2011-Efectis-R0495 • UL 10 (b) (2009) • UL 10 (c) (2009) • UL 10 (d) (2009) • NFPA 252 (2012)

Closing direction

From top to bottom

Fire resistance

E 30 • E 60 • E 90 • E 120 • EW 30 • EW 60 • EW 90 • EW 120 • classified according to DIN EN 13501-2

Closing cycles

C2

  • Fibershield-P
  • Fibershield-P
  • Fibershield-P
  • Fibershield-P
  • Fibershield-P
  • Fibershield-P
Constructive system design - System drawing

1Smoke detector2Casing3Side guide4Fixing bracket5Fabric6Closing element7Tubular motor8Control module9Control with operating unit10Manual release


1Smoke detector2Casing3Side guide4Fixing bracket5Fabric6Closing element7Tubular motor8Control module9Control with operating unit10Manual release

Classification

Fabric

System width

Drop length (AL)

t (mm)

h (mm)

EW 90

Heliotex EW

≥ 0.8 m - ≤ 10 m

≤ 2 m

190

250

EW 90

Heliotex EW

≥ 0.8 m - ≤ 10 m

≤ 6 m

235

290

E 90 / EW 30

Protex 1100.1 A2

≥ 0.8 m - ≤ 1.6 m

≤ 3.5 m

190

250

E 90 / EW 30

Protex 1100.1 A2

≥ 1.6 m - ≤ 10 m

≤ 3.5 m

190

200

E 90 / EW 30

Protex 1100.1 A2

≥ 0.8 m - ≤ 10 m

≥ 3.5 m - ≤ 6 m

190

250

E 90 / EW 30

Protex 1100.1 A2

≥ 0.8 m - ≤ 10 m

≥ 6 m - ≤ 7.6 m

235

290

Special sizes on request - technically feasible up to dimensions 22 x 9m (Protex 1100.1 A2) or 12 x 6 m (Heliotex)

Closing strips

Standard

Standard

Closing strips - Standard

Type4,6

Special

Spring-loaded closing strip

 - Spring-loaded closing strip

Type3,84 F (Special)

Spring-loaded closing strip

 - Spring-loaded closing strip

Type4,6 F (Special)

Casing installation options

Wall mounting

Suspension mounting

Ceiling mounting

Guide rails

Standard

Type 105 E (niche)

Guide rails - Type 105 E (niche)

a105 mmb74 mmAL≤ 6 mA≤ 50 m²

Type 105 E (embrasure)

Guide rails - Type 105 E (embrasure)

a105 mmb74 mmAL≤ 6 mA≤ 50 m²

Type 105 E(Wall)

Guide rails - Type 105 E(Wall)

a105 mmb74 mmAL≤ 6 mA≤ 50 m²

Type 80 E

Guide rails - Type 80 E

a80 mmb74 mmAL≤ 3,5 mA≤ 18 m²

Type 160 E

Guide rails - Type 160 E

a160 mmb100 mmAL≤ 9 mA≤ 120 m²
